The LUMISTAR Hygienic Sintered Glass Window is a compact glass-to-metal viewing component developed for hygienic process equipment and sterile production lines. Combining a sintered borosilicate glass element with a metal holding ring, it provides a dedicated viewing area for monitoring process conditions in compatible tanks, pipelines and sanitary equipment.

During manufacturing, the glass element is integrated with a metal holder through a controlled sintering and joining process. This construction is designed to provide a secure glass-to-metal assembly for industrial observation applications. The final performance depends on the glass structure, metal material, manufacturing process and installation conditions.

The compact, low-profile design is intended for installations where space is limited and hygienic construction is important. When matched with a compatible fitting, the viewing window can support process observation while helping minimise unnecessary dead space around the connection. Proper installation and cleaning procedures remain essential for hygienic operation.

The product is designed for compatible NA-Connect and hygienic fitting systems, including connection configurations associated with DIN 32676 and ISO 2852. Available mounting arrangements and dimensions should be confirmed against the required connection standard and equipment design before ordering.

The glass element is made from sintered borosilicate glass, while the housing or holding ring can be manufactured from stainless steel 304 or 316, depending on the configuration. Duplex stainless steel and selected nickel-based alloys may also be considered for specific requirements. Material selection should take into account the process medium, cleaning chemicals, operating temperature and corrosion conditions.
